Building a Search Engine With Nutch Solr And Hadoop









The World Wide Web (WWW) is an ocean of information, in fact a kid can stay at home from birth and learn everything without going to school a single day through the WWW (despite the fact that he would become a complete idiot at the end).

Swimming through this ocean and finding what is relevant to you is the duty of a web search engine. It has to crawl through the web, know which site contains which information and keep a record of that so that it can provide with relevant URL’s and data. Google has been the leading web search Engine throughout but now there are others such as Microsoft’s Bing which some say presents more focused results than Google.

Following steps describes building a search engine using Nutch and Solr, I did this for my organization IMS Health as a search Engine for Life sciences. Nutch and Solr are Apache Software’s and hence Open source. Nutch is a Web Crawler, which means it will look at a list of URL’s and bring in the data that is contained on those web pages. Solr is an open source search platform based on Apache Lucene Engine.  Web Crawling is a tremendous task which requires extensive processing power and network bandwidth, because of this I run the nutch crawler on top of Hadoop which is another Apache product, Hadoop is a distributed processing and storage system that can be implemented on common hardware systems without the requirement of high end servers.

In short, nutch will work on crawling on top of hadoop and give the results to solr, solr will produce an index(inverted index as Solr describes) to give amazingly fast search responses to the user, solr will give results in the form of XML or JSON.


Softwares Applications Used:

  • Apache Nutch 1.7 as the crawler
  • Apache Solr 4.6.0 as the search indexing engine
  • Apache Hadoop 1.2.1 as the distributed processing environment
  • Apache Ant builder tool
  • Java Version 1.7.0
  • Cent OS 5.9 on the server
  • SSH configured on the server
  • Create a dedicated user named hadoop with password hadoop for this operation
  • Change on to the hadoop user
  • Enable SSH access to local machine with new key
  • Test SSH coonection to local machine with
  • Download Apache Solr (Latest version as present date is 4.6.1)
  • Extract the download
  • Rename the directory as solr
  • Navigate to the example directory inside solr and start solr using start.jar
  • This will start solr on jetty with the default port of 8983, you can check solr admin panel on http://<your domain>:8983/solr/
  • Download apache ant binary
  • Extract downloaded source
  • Set ANT_HOME variable in /etc/profile
  • At the end add the following lines
  • Set the variable value

Note: The URLS mentioned in the wget will be changed, searching through the archives will give you the accurate URLS.

Dedicated User creation:


useradd hadoop
passwd hadoop
> hadoop


su – hadoop

Configure SSH:

   ssh-keygen -t rsa -P ""


     cat $HOME/.ssh/id_rsa.pub >> $HOME/.ssh/authorized_keys



     ssh localhost

Apache Solr Installation:





tar zxf solr-4.6.1.tgz


            sudo mv solr-4.6.1 solr


            cd solr/example
            java –jar start.jar



Apache Ant Installation






             tar -zxf apache-ant-1.9.2-bin.tar.gz



             sudo vi /etc/profile



            export ANT_HOME= /apache-ant-1.9.2
export PATH=$PATH:$ANT_HOME/bin



               source /etc/profile

Apache Hadoop Installation

Download Hadoop 1.2.1


Extract and rename

                  sudo tar xzf hadoop-1.2.1.tar.gz

                  sudo mv hadoop-1.2.1 hadoop

                   sudo chown hadoop:hadoop hadoop

Update /profile


                    sudo vi  /etc/profile

Add the following lines at the end of the profile

# Set Hadoop-related environment variables
export HADOOP_HOME = ~/hadoop

# Set JAVA_HOME (we will also configure JAVA_HOME directly for Hadoop later on)
export JAVA_HOME=/usr/lib/jvm/java-1.7.0-openjdk

# Some convenient aliases and functions for running Hadoop-related commands
unalias fs &> /dev/null
alias fs="hadoop fs"
unalias hls &> /dev/null
alias hls="fs -ls"

# If you have LZO compression enabled in your Hadoop cluster and
# compress job outputs with LZOP (not covered in this tutorial):
# Conveniently inspect an LZOP compressed file from the command
# line; run via:
#
# $ lzohead /hdfs/path/to/lzop/compressed/file.lzo
#
# Requires installed 'lzop' command.
#
lzohead () {
    hadoop fs -cat 34054 | lzop -dc | head -1000 | less
}

# Add Hadoop bin/ directory to PATH
export PATH=$PATH:$HADOOP_HOME/bin

Edit hadoop-env.sh and add java home

cd ~/hadoop

                  sudo vi conf/hadoop-env.sh

# The java implementation to use.  Required.
JAVA_HOME='/usr/lib/jvm/java-1.7.0-openjdk'

Create hadoop tmp folder and create ownership to hadoop

            sudo mkdir /app/hadoop/tmp

            sudo chown hadoop:hadoop /app/hadoop/tmp

Edit conf/core-site.xml

             sudo vi conf/core-site.xml

Add the following lines
<property>
  <name>hadoop.tmp.dir</name>
  <value>/app/hadoop/tmp</value>
  <description>A base for other temporary directories.</description>
</property>
<property>
  <name>fs.default.name</name>
 < value>hdfs://localhost:54310</value>
  <description>The name of the default file system.  A URI whose
  scheme and authority determine the FileSystem implementation.  The
  uri's scheme determines the config property (fs.SCHEME.impl) naming
  the FileSystem implementation class.  The uri's authority is used to
  determine the host, port, etc. for a filesystem.</description>
</property>

Edit conf/mapred-site.xml

                  sudo vi conf/mapred-site.xml

Add the following lines

<property>
  <name>mapred.job.tracker</name>
  <value>localhost:54311</value>
  <description>The host and port that the MapReduce job tracker runs
  at.  If "local", then jobs are run in-process as a single map
  and reduce task.
  </description>
</property>

Edit conf/hdfs-site.xml

sudo vi conf/hdfs-site.xml

Add the following lines

<property>
  <name>dfs.replication</name>
  <value>1</value>
  <description>Default block replication.
  The actual number of replications can be specified when the file is created.
  The default is used if replication is not specified in create time.
  </description>
</property>

Format the HDFS via the single name node

                  bin/hadoop namenode –format

Start the single node cluster

                  bin/start-all.sh

Use jps to check if all the tasks are running

                  jps


Output should display TaskTracker, Job Tracker, Namenode, Secondary Namenode and Job Tracker

Hadoop Debugging tips

     In order to restart hadoop, perform the following steps:

cd  ~/hadoop
bin/stop-all.sh

Delete the hadoop temp folder and recreate it with necessary access rights

sudo rm –r /app/hadoop/tmp
sudo mkdir /app/hadoop/tmp
sudo chmod 777 –R /app/hadoop/tmp (777 is given for this example purpose only)
bin/hadoop namenode –format
bin/start-all.sh


If any of the components are not starting up, refer to the hadoop logs for any exceptions. Hadoop logs are located in the logs/ subdirectory in hadoop root. For each of the five processes on hadoop separate logs are created.

Apache Nutch Installation

Download nutch version 1.7 (download the src in order to run with hadoop)


Extract the download and rename the folder

sudo tar zxf apache-nutch-1.7-src.tar.gz
            sudo mv apache-nutch-1.7-src nutch

Copy conf/nutch-default.xml to conf/nutch-site.xml

            cd nutch/conf
            sudo mv nutch-site.xml nutch-site_bak.xml
            sudo cp nutch-default.xml nutch-site.xml

Edit nutch-site.xml and set the name of your crawler for the http.agent.name property

          sudo vi nutch-site.xml

          edit:
           <name>http.agent.name</name>
           <value>Your Name<value>

Copy hadoop-env.sh, core-site.xml, hdfs-site.xml, mapred-site.xml from ~/hadoop/conf to ~/nutch/conf

       sudo cp ~/hadoop/conf/hadoop-env.sh ~/nutch/conf
       sudo cp ~/hadoop/conf/hdfs-site.xml ~/nutch/conf
       sudo cp ~/hadoop/conf/mapred-site.xml ~/nutch/conf
       sudo cp ~/hadoop/conf/core-site.xml ~/nutch/conf

Edit nutch default.properties and

       cd ~/nutch
      sudo vi default.properties

Change name from apache-nutch to nutch in default.properties

Build nutch using ant

            cd ~/nutch
            sudo ant runtime

Create classpath


            export CLASSPATH=~/nutch/runtime/local/lib

 Making Solr compatible with Nutch

Rename schema.xml in solr/example/solr/collection1/conf

mv ${APACHE_SOLR_HOME}/example/solr/collection1/conf/schema.xml ${APACHE_SOLR_HOME}/example/solr/collection1/conf/schema.xml.org

Move the nutch schema-solr4.xml into solr/example/solr/collection1/conf and rename to schema.xml

cp ${NUTCH_RUNTIME_HOME}/conf/schema-solr4.xml ${APACHE_SOLR_HOME}/example/solr/collection1/conf/schema.xml

Edit the new schema.xml

vi ${APACHE_SOLR_HOME}/example/solr/collection1/conf/schema.xml

Copy exactly in 351 line: <field name="_version_" type="long" indexed="true" stored="true"/>
restart Solr with the command “java -jar start.jar” under ${APACHE_SOLR_HOME}/example

Running the crawl

Create URLS file in nutch

cd ~/nutch
sudo mkdir urls
cd ~/nutch
sudo nano seed.txt

Add the necessary urls to this file one per each line(Three example URLS used below)

http://diabetesdailypost.com/
http://www.allfortheboys.com/

Put the urls folder to HDFS

cd ~/hadoop
bin/hadoop dfs –moveFromLocal  ~/nutch/urls urls

Check whether the file exists, the urls folder will be created under /user/hadoop

bin/hadoop dfs –ls

Finally run the nutch crawl on hadoop and add the data to solr index


bin/hadoop jar /home/hadoop/nutch/runtime/deploy/nutch-1.7.job org.apache.nutch.crawl.Crawl urls -solr http://localhost:8983/solr/ -depth 5 -topN 5

Using the Hadoop web interfaces

You can check the status of the hadoop jobs that are currently running with the job tracker and HDFS web interfaces

 http://<your domain>:50030 – Job tracker interface

 http://<your domain>:50070 – HDFS interface

References:

http://www.cyberciti.biz/faq/howto-add-new-linux-user-account/
http://www.michael-noll.com/tutorials/running-hadoop-on-ubuntu-linux-single-node-cluster/
http://wiki.apache.org/nutch/NutchTutorial
http://www.sysadminhub.in/2013/07/installing-apache-ant-on-linux-centos.html

         http://blog.cloudera.com/blog/2009/08/hadoop-default-ports-quick-    reference/
