Introduction

Check Already Published in this Series section to know what was seen before.

In this article, we will focus on CoreModifiable methods. CoreModifiable methods are methods that can be called by their name without knowing the exact type of the called instance.

Fast Access Fixed Prototype Methods

Fixed prototype is:

bool    methodName(CoreModifiable* sender,
        kstl::vector<CoreModifiableAttribute*>& params,void* privateParams);

Parameters are:

• CoreModifiable* sender: caller class
• kstl::vector<CoreModifiableAttribute*>& params: vector of CoreModifiableAttribute* parameters
• void* privateParams: a possible user defined private param

Return value is a bool value. Meaning of the return value is user defined.

Helper macros can be used to declare a member method: DECLARE_METHOD, DECLARE_VIRTUAL_METHOD, DECLARE_PURE_VIRTUAL_METHOD.

// declare member method called "GiveInfos"
DECLARE_METHOD(GiveInfos);

Helper macro DEFINE_METHOD is then used to define method:

Hide   Shrink    Copy Code

// define member method named GiveInfos on SimpleClass
DEFINE_METHOD(SimpleClass, GiveInfos)
{

    std::cout << "SimpleClass GiveInfos method called on
                 " << getName() << " instance" << std::endl;
    std::cout << "-- sender : " << sender->getName() << std::endl;

    for (auto p : params)
    {
#ifdef KEEP_NAME_AS_STRING
        std::string v;
        if (p->getValue(v))
        {
            std::cout << "-- parameter : " << p->getID()._id_name <<
                         " value is : " << v << std::endl;
        }
        else
        {
            std::cout << "-- parameter : " << p->getID()._id_name <<
                         " value cannot be evaluated as string" << std::endl;
        }
#else
        std::string v;
        if (p->getValue(v))
        {
            std::cout << "-- parameter : " << p->getID()._id <<
                         " value is : " << v << std::endl;
        }
        else
        {
            std::cout << "-- parameter : " << p->getID()._id <<
                         " value cannot be evaluated as string" << std::endl;
        }
#endif
    }

    if(privateParams)
        std::cout << "-- private parameter is not null" << std::endl;
    else
        std::cout << "-- private parameter is null" << std::endl;

    return true;
}

Fast Call

Then method can be called with "CallMethod" like this:

// create dynamic attribute on this
AddDynamicAttribute<maFloat, float>("FloatParam", 12.0f);

// create CoreModifiableAttribute without owner
CoreModifiableAttribute* intParam = new maInt("IntParam", 15);

// create a parameter vector
std::vector<CoreModifiableAttribute*> params;
// push dynamic attribute "FloatParam" on vector
params.push_back(getAttribute("FloatParam"));
// push intParam
params.push_back(intParam);

// call GiveInfos on instance1 with params vector, no private parameter, and sender is this
bool result = instance1->CallMethod("GiveInfos", params, nullptr, this);
std::cout << "GiveInfos returns " << (result?"true":"false") << std::endl << std::endl;

// call GiveInfos on instance1 with this instance (Sample4) as parameter,
// no private params and no sender
// so the received parameter vector will be all the CoreModifiable attributes owned by this
result = instance1->CallMethod("GiveInfos", this, nullptr, nullptr);
std::cout << "GiveInfos returns " << (result ? "true" : "false") << std::endl << std::endl;

Slower Simple Call

The SimpleCall template method automatically encodes parameters in vector:

// "SimpleCall" on instance2:
result = instance2->SimpleCall("GiveInfos", 32,64,5);
std::cout << "GiveInfos returns " << (result ? "true" : "false") << std::endl << std::endl;

Returned Value

Returned value can be pushed on parameter vector with helper macro PUSH_RETURN_VALUE.
When called using CallMethod, the returned value and allocated parameters must be deleted after the call (or a memory leaks will occur).

경축! 아무것도 안하여 에스천사게임즈가 새로운 모습으로 재오픈 하였습니다.
어린이용이며, 설치가 필요없는 브라우저 게임입니다.
https://s1004games.com

// call GiveInfos on instance2 with params vector, no private parameter and sender is this
int paramsCount = params.size();
result = instance2->CallMethod("GiveInfos", params, nullptr, this);
if (params.size() > paramsCount)
{
    // return values added
    while(paramsCount<params.size())
    {
        std::string v;
        if(params.back()->getValue(v))
            std::cout << "GiveInfos returned value = " << v << std::endl;

        delete params.back();
        params.pop_back();
    }
}
std::cout << "GiveInfos returns " << (result ? "true" : "false") << std::endl << std::endl;

With SimpleCall, the returned value can be managed automatically with template parameter:

// "SimpleCall" on instance2:
float floatresult = instance2->SimpleCall<float>("GiveInfos", 32,64,5);
std::cout << "GiveInfos returns " << floatresult << std::endl << std::endl;

Slower Access Wrapped Methods

Any member method can be wrapped as a CoreModifiable method. In class declaration:

float Multiply(float v1, float v2)
{
    return v1 * v2;
}
// Multiply method can be called with SimpleCall
WRAP_METHODS(Multiply);

Then Multiply method can be called like this:

float floatresult = instance2->SimpleCall<float>("Multiply", 32, 5);
std::cout << "instance2 Multiply returns " << floatresult << std::endl << std::endl;

Dynamic Methods

CoreModifiable inherited instances can be enhanced with dynamic method.

A dynamic method can be defined like this:

// declare a dynamic method named addValues which can be added to any CoreModifiable instance
DEFINE_DYNAMIC_METHOD(CoreModifiable, addValues)
{
    float result = 0.0f;
    for (auto p : params)
    {
        float v;
        if (p->getValue(v))
        {
            result += v;
        }
    }
    PUSH_RETURN_VALUE(result);
    return true;
}

Then at run time, add this method to a given instance, and call it with SimpleCall:

// now add addValues method on instance2, calling name is also addValues
instance2->INSERT_DYNAMIC_METHOD(addValues, addValues);
floatresult = instance2->SimpleCall<float>("addValues", 32, 5);
std::cout << "instance2 addValues returns " << floatresult << std::endl << std::endl;

This mechanism can be used to decorate instances with a specific behaviour.

Find all the sample code from this article in Sample4 project (browse the code).

Already Published in this Series

1. Kigs Framework Introduction (1/8) - Overview
2. Kigs Framework Introduction (2/8) - CoreModifiable
3. Kigs Framework Introduction (3/8) - Attributes
4. Kigs Framework Introduction (4/8) - Methods
5. Kigs Framework Introduction (5/8) - CoreItem

History

• 13^th February, 2020: Initial version
• 21^st February, 2020: Article (5/8) added to the series
